Specifications
Series |
720 |
Assembly Type |
Plug Bag Assembly |
Altitude/Reduced Pressure Rating |
70,000 ft. |
Current Rating |
10 Amp4 Amp6 Amp |
Operating Temperature |
-55 to 125 ºC |
Test Voltage |
25 kVDC at 70,000 ft. (simulated) at ambient temperature |
Mating Compatibility |
Mates all series 720 receptacles and LGH LI series receptacles. Also mates Reynolds C720 series RC1525 and 3RC1525 receptacles; this combination will reduce the upper operating temperature from +125ºC to +95ºC |
Insulator Material |
Silicone |
Sealed Receptacle |
N/A |
| Standard/Non-Standard1 | Standard Part |
Coupling Style |
Threaded |
Export Classification |
TBD |
RoHS Compliant |
TBD |
| LGH™ Compatibility2 | LGH 1I |
Voltage Rating |
20 kVDC |
Wire Type |
Silicone |
Contact Properties
Contact Type |
Female |
Contact Material |
BeCu |
Contact Finish |
Gold |
Female Contact Hood Material |
Stainless Steel |
