| TYPE | DESCRIPTION |
| Category | Connectors, Interconnects |
| D-Sub, D-Shaped Connectors | |
| D-Sub Connector Assemblies | |
| Mfr | Cinch Connectivity Solutions |
| Series | 3 |
| Package | – |
| Product Status | Active |
| Connector Style | D-Sub |
| Connector Type | Receptacle, Female Sockets |
| Number of Positions | 25 |
| Number of Rows | 2 |
| Mounting Type | Free Hanging (In-Line) |
| Shell Size, Connector Layout | 3 (DB, B) |
| Contact Type | Signal |
| Flange Feature | Housing/Shell (Unthreaded) |
| Termination | Crimp |
| Shell Material, Finish | Steel, Yellow Chromate Plated Zinc |
| Contact Finish | Gold |
| Contact Finish Thickness | 30.0µin (0.76µm) |
| Ingress Protection | – |
| Material Flammability Rating | UL94 V-0 |
| Current Rating (Amps) | 5A |
| Backset Spacing | – |
| Features | – |
| Voltage Rating | – |
| Color | Green |
| Contact Form | Machined |
| Dielectric Material | Diallyl Phthalate (DAP), Glass Filled |
| Wire Gauge | – |
| Contact Material | Phosphor Bronze |
| Operating Temperature | -65°C ~ 125°C |
| Base Product Number | DBMA25 |
D-Sub
DBMA25S
9,800,000 تومان
25 Position D-Sub Receptacle, Female Sockets Connector
دسترسی: 490 در انبار
توضیحات
توضیحات تکمیلی
| سازنده | |
|---|---|
| رده | MIL |
