| TYPE | DESCRIPTION |
| Category | Discrete Semiconductor Products |
| Transistors | |
| JFETs | |
| Mfr | MOTOROLA |
| Series | Military, MIL-PRF-19500/375 |
| Package | Bulk |
| Product Status | Active |
| FET Type | N-Channel |
| Voltage – Breakdown (V(BR)GSS) | 30 V |
| Drain to Source Voltage (Vdss) | 30 V |
| Current – Drain (Idss) @ Vds (Vgs=0) | 20 mA @ 15 V |
| Voltage – Cutoff (VGS off) @ Id | 8 V @ 500 pA |
| Input Capacitance (Ciss) (Max) @ Vds | 6pF @ 15V |
| Power – Max | 300 mW |
| Operating Temperature | -55°C ~ 200°C (TJ) |
| Mounting Type | Through Hole |
| Package / Case | TO-206AF, TO-72-4 Metal Can |
| Supplier Device Package | TO-72 |
| Base Product Number | 2N3823 |
| Alternative | JX2N3823 JXV2N3823 JTXV2N3823 |
