جاذب امواج الکترومغناطیسی با دمای بالا
Eccosorb™ MF500 – MF500F
Product Description
This high temperature absorber product line is designed for use at short periods of 500 °F (260 °C) permitting use at high ambients and/or high power levels. Physical and electrical properties are the same as those of the corresponding member of the ECCOSORB MF series.
Features and Benefits
– Rigid
– Machinable
– High temperature 260°c
Technical Specification
-
Typical Properties
ColorDark GreyDensity (g/cc)1.60FunctionTermination, attenuator, isolationOperating Temperature Max (Celsius)260ResinEpoxyShelf LifeMinimum 720 Days from Date of ShipmentTypeThermoset machinable stock -
Thermal Properties
Thermal Conductivity (W/mK)1.44 -
Electromagnetic Properties
Attenuation<217 dB/cm at 18 GhzProduct Frequency Range1 – 18 Ghz -
Mechanical Properties
Coefficient of linear expansion (cm/cm/°c)0.000061Hardness85 shore DTensile Strength (Mpa)55.0 -
Dimensions
Thickness Max (mm)50.80Thickness Min (mm)3.20 -
Compliance
REACHYesROHS CompliantYes -
Options
Option Availability – MachiningYesOption Availability – PSAYesOption Availability – on drawingYes
