| TYPE | DESCRIPTION |
| Category | Integrated Circuits (ICs) |
| Interface | |
| Analog Switches, Multiplexers, Demultiplexers | |
| Manufacturer | Analog Devices Inc. |
| Series | – |
| Packaging | Bulk |
| Part Status | Active |
| Switch Circuit | – |
| Multiplexer/Demultiplexer Circuit | 16:01 |
| Number of Circuits | 1 |
| On-State Resistance (Max) | 800Ohm |
| Channel-to-Channel Matching (ΔRon) | 29Ohm |
| Voltage – Supply, Single (V+) | 15V |
| Voltage – Supply, Dual (V±) | ±15V |
| Switch Time (Ton, Toff) (Max) | 2.5µs, 500ns |
| -3db Bandwidth | – |
| Charge Injection | – |
| Channel Capacitance (CS(off), CD(off)) | 2.5pF, 13pF |
| Current – Leakage (IS(off)) (Max) | 2nA (Max) |
| Crosstalk | -70dB @ 100kHz |
| Operating Temperature | -55°C ~ 125°C (TA) |
| Mounting Type | Through Hole |
| Package / Case | 28-CDIP (0.600″, 15.24mm) |
| Supplier Device Package | 28-CDIP |
Alternates: MUX-16BT/883, MUX16BT883, 5962-87717, 59628771702XA, 5962-8771702XA, 0338703, 033870-3, 26988642, 2698-8642, 5962-01-244-7781, 01-244-7781, 5962012447781, 012447781, 596287717
