| TYPE | DESCRIPTION |
| Category | Integrated Circuits (ICs) |
| Interface | |
| Analog Switches, Multiplexers, Demultiplexers | |
| Mfr | Analog Devices Inc. |
| Series | – |
| Package | Bulk |
| Product Status | Active |
| Switch Circuit | – |
| Multiplexer/Demultiplexer Circuit | 16:01 |
| Number of Circuits | 100.00% |
| On-State Resistance (Max) | 800Ohm |
| Channel-to-Channel Matching (ΔRon) | 29Ohm |
| Voltage – Supply, Single (V+) | 15V |
| Voltage – Supply, Dual (V±) | ±15V |
| Switch Time (Ton, Toff) (Max) | 2.5µs, 500ns |
| -3db Bandwidth | – |
| Charge Injection | – |
| Channel Capacitance (CS(off), CD(off)) | 2.5pF, 13pF |
| Current – Leakage (IS(off)) (Max) | 2nA (Max) |
| Crosstalk | -70dB @ 100kHz |
| Operating Temperature | -55°C ~ 125°C (TA) |
| Mounting Type | Through Hole |
| Package / Case | 28-CDIP (0.600″, 15.24mm) |
| Supplier Device Package | 28-CDIP |
آی سی تراشه - IC
MUX16BT/883C
1,400,000 تومان
1 Circuit IC Switch 16:1 800Ohm 28-CDIP
دسترسی: 12 در انبار
توضیحات
توضیحات تکمیلی
| سازنده | |
|---|---|
| طرح بسته بندی | DIP-16, DIP-8 |
