| Type | Description |
| Category | Integrated Circuits (ICs) |
| Power Management (PMIC) | |
| DC DC Switching Controllers | |
| Manufacturer | Microchip Technology |
| Series | – |
| Packaging | Tube |
| Part Status | Obsolete |
| Output Type | Transistor Driver |
| Function | Step-Up/Step-Down |
| Output Configuration | Positive |
| Topology | Flyback |
| Number of Outputs | 2 |
| Output Phases | 1 |
| Voltage – Supply (Vcc/Vdd) | 7V ~ 40V |
| Frequency – Switching | 50kHz ~ 600kHz |
| Duty Cycle (Max) | 49% |
| Synchronous Rectifier | Yes |
| Clock Sync | No |
| Serial Interfaces | – |
| Control Features | Enable |
| Operating Temperature | -25°C ~ 85°C (TA) |
| Mounting Type | Through Hole |
| Package / Case | 16-CDIP (0.300", 7.62mm) |
| Supplier Device Package | 16-CERDIP |
| Base Product Number | SG2524 |
آی سی تراشه - IC
SG2524BJ
تماس جهت استعلام قیمت واردات
Flyback Regulator Positive Output Step-Up/Step-Down DC-DC Controller IC 16-CERDIP
