| TYPE | DESCRIPTION |
| Category | Connectors, Interconnects |
| Rectangular Connectors | |
| Headers, Male Pins | |
| Mfr | TE Connectivity AMP Connectors |
| Series | Universal MATE-N-LOK |
| Package | Bulk |
| Product Status | Active |
| Connector Type | Header |
| Contact Type | Male Pin |
| Pitch – Mating | 0.250″ (6.35mm) |
| Number of Positions | 8 |
| Number of Rows | 1 |
| Row Spacing – Mating | – |
| Number of Positions Loaded | All |
| Style | Board to Cable/Wire |
| Shrouding | Shrouded – 4 Wall |
| Mounting Type | Through Hole |
| Termination | Solder |
| Fastening Type | Locking Ramp |
| Contact Length – Mating | – |
| Contact Length – Post | 0.155″ (3.94mm) |
| Overall Contact Length | – |
| Insulation Height | 0.550″ (13.97mm) |
| Contact Shape | Circular |
| Contact Finish – Mating | Tin |
| Contact Finish Thickness – Mating | – |
| Contact Finish – Post | Tin |
| Contact Material | Phosphor Bronze |
| Insulation Material | Polyamide (PA), Nylon |
| Features | – |
| Operating Temperature | -40°C ~ 105°C |
| Ingress Protection | – |
| Material Flammability Rating | UL94 V-2 |
| Insulation Color | White |
| Current Rating (Amps) | 12A |
| Voltage Rating | 600VAC |
| Mated Stacking Heights | – |
| Contact Finish Thickness – Post | – |
| Applications | General Purpose |
| Base Product Number | 641825 |
هدر - Header
641825-1
280,000 تومان
Connector Header Through Hole 8 position 0.250″ (6.35mm)
دسترسی: 47 در انبار
