| TYPE | DESCRIPTION |
| Category | Connectors, Interconnects |
| Rectangular Connectors | |
| Headers, Male Pins | |
| Mfr | Molex |
| Series | SL 70543 |
| Package | Tube |
| Product Status | Active |
| Connector Type | Header |
| Contact Type | Male Pin |
| Pitch – Mating | 0.100″ (2.54mm) |
| Number of Positions | 7 |
| Number of Rows | 1 |
| Row Spacing – Mating | – |
| Number of Positions Loaded | All |
| Style | Board to Cable/Wire |
| Shrouding | Shrouded – 4 Wall |
| Mounting Type | Through Hole |
| Termination | Solder |
| Fastening Type | Latch Holder |
| Contact Length – Mating | 0.240″ (6.10mm) |
| Contact Length – Post | 0.130″ (3.30mm) |
| Overall Contact Length | 0.470″ (11.94mm) |
| Insulation Height | 0.465″ (11.80mm) |
| Contact Shape | Square |
| Contact Finish – Mating | Gold |
| Contact Finish Thickness – Mating | 15.0µin (0.38µm) |
| Contact Finish – Post | Tin |
| Contact Material | Phosphor Bronze |
| Insulation Material | Polyester, Glass Filled |
| Features | – |
| Operating Temperature | -40°C ~ 105°C |
| Ingress Protection | – |
| Material Flammability Rating | UL94 V-0 |
| Insulation Color | Black |
| Current Rating (Amps) | – |
| Voltage Rating | 250V |
| Mated Stacking Heights | – |
| Contact Finish Thickness – Post | 74.8µin (1.90µm) |
| Applications | Automotive, General Purpose, Industrial, Medical |
| Base Product Number | 70543 |
هدر - Header
0705430006
140,000 تومان
Connector Header Through Hole 7 position 0.100″ (2.54mm)
دسترسی: 200 در انبار
